GPS/Nav/Com Systems

As market leader in general aviation avionics Garmin offers a broad range of panel mount GPS units, some of which also integrate VHF Com and Nav, and optional TAWS. With the all new GPS175, Garmin brings an entry-level IFR GPS navigator making WAAS upgrades with LPV capability more affordable than ever before.
Recently, Avidyne has entered the arena of GPS navigation systems with the IFD series.
The still very popular Garmin GNS430W and GNS530W have been discontinued since late 2013.
Contact us for more details and a quotation.

Garmin GPS/GNX Series
GPS Systems:
GPS/Transponder:

Garmin GTN Xi Series
GPS/Nav/Com Systems:

GPS/Com Systems:
GPS Systems:

Accessories:

Avidyne IFD Series
GPS/Nav/Com Systems:

>> DISCONTINUED <<
GPS/Nav/Com Systems:

GPS/Com Systems:
GPS Systems:

Garmin GPS175
Garmin GNX375

Garmin GTN750Xi
Garmin GTN650Xi
Garmin GTN635Xi
Garmin GTN725Xi
Garmin GTN625Xi

Garmin FlightStream 510
Garmin FlightStream 210

Avidyne IFD550/540
Avidyne IFD440

Garmin GNS530(W)
Garmin GNS430(W)
Garmin GNC420(W)
Garmin GPS500(W)
Garmin GPS400(W)

Garmin GPS175/GNX375

Garmin GPS 175 - GPS

         ● Entry-level IFR GPS/WAAS navigator,
         ● Menu-driven graphical interface,
         ● 4.8" (12,2 cm) LCD touchscreen display, 724x240 pix,
         ● GPS TSO'd to C146c, authorized for class 1,2,3 (LPV),
       ● GPS-WAAS-certified to Gamma-3 approach capability,
         ● Analog and digital interface provisions for:
              EFIS/HSI, navigation indicator, Multi-Function Display,
              transponder,
         ● Integrated Bluetooth Connext interface,
         ● Flight control system interface for autopilot,
         ● Weight: 0,60 kg

          More info                        Price: contact us

Garmin GNX375 - GPS/Transponder

         ● IFR GPS/WAAS navigator met Mode S transponder,
         ● Menu-driven graphical interface,
         ● 4.8" (12,2 cm) LCD touchscreen display, 732x240 pix,
         ● GPS TSO'd to C146c, authorized for class 1,2,3 (LPV),
       ● GPS-WAAS-certified to Gamma-3 approach capability,
         ● Analog and digital interface provisions for:
              EFIS/HSI, navigation indicator, Multi-Function Display
         ● Flight control system interface voor autopilot,
         ● Integrated Mode S & ADS-B transponder,
         ● 1090ES ADS-B out; dual link ADS-B in,
         ● Weight: 1,45 kg

          More info                        Price: contact us

GPS/Nav/Com

Garmin GTN 750Xi - GPS/Nav/Com

         ● Menu-driven graphical interface,
         ● 6.9" (17.5 cm) LCD touchscreen display, 600x708 pix,
         ● Feature-rich MFD capabilities,
         ● GPS TSO'd to C146c, authorized for class 1,2,3 (LPV),
       ● GPS-WAAS-certified to Gamma-3 approach capability,
       ● Built-in GPS/ILS/VOR/LOC and glideslope capabilities,
         ● VHF com transceiver with 25 or 8.33 kHz spacing,
         ● Com transmit power: 10W standard, 16W optional,
         ● Optional interface capabilities: lightning, weather,
              traffic, TAWS-B terrain alerting, and more,
         ● Integrated contol/display for remote transponders
         ● Integrated control for remote audio panel functions,
         ● Flight control system interface for select autopilots,
         ● Weight: 4,24 kg

         More info                           Price: contact us

Garmin GTN 650Xi - GPS/Nav/Com

         ● Menu-driven graphical interface,
         ● 4.9" (12.4 cm) LCD touchscreen display, 600x266 pix,
         ● Feature-rich MFD capabilities,
         ● GPS TSO'd to C146c, authorized for class 1,2,3 (LPV),
       ● GPS-WAAS-certified to Gamma-3 approach capability,
       ● Built-in GPS/ILS/VOR/LOC and glideslope capabilities,
         ● VHF com transceiver with 25 or 8.33 kHz spacing,
         ● Com transmit power: 10W standard, 16W optional,
         ● Optional interface capabilities: lightning, weather,
              traffic, TAWS-B terrain alerting, and more,
         ● Integrated contol/display for remote transponders,
         ● Flight control system interface for select autopilots,
         ● Weight: 3,2 kg

          More info                           Price: contact us

Avidyne IFD 540 - GPS/Nav/Com

         ● Menu-driven graphical interface,
         ● 5.7" (14.6 cm) LCD touchscreen display, 640x480 pix,
         ● Feature-rich MFD capabilities,
         ● GPS TSO'd to C146c, authorized for class 1,2,3 (LPV),
       ● GPS-WAAS-certified to Gamma-3 approach capability,
       ● Built-in GPS/ILS/VOR/LOC and glideslope capabilities,
         ● VHF com transceiver with 25 or 8.33 kHz spacing,
         ● Com transmit power: 10W standard, 16W optional,
         ● Optional interface capabilities: lightning, weather,
              traffic, TAWS-B terrain alerting, and more,
         ● Plug & play comptible with Garmin GNS530,
         ● Flight management system interface,
         ● Weight: 3,8 kg

          More info                           Price: contact us

Avidyne IFD 440 - GPS/Nav/Com

         ● Menu-driven graphical interface,
         ● 4.8" (12.1 cm) LCD touchscreen display, 640x235 pix,
         ● Feature-rich MFD capabilities,
         ● GPS TSO'd to C146c, authorized for class 1,2,3 (LPV),
       ● GPS-WAAS-certified to Gamma-3 approach capability,
       ● Built-in GPS/ILS/VOR/LOC and glideslope capabilities,
         ● VHF com transceiver with 25 or 8.33 kHz spacing,
         ● Com transmit power: 10W standard, 16W optional,
         ● Optional interface capabilities: lightning, weather,
              traffic, TAWS-B terrain alerting, and more,
         ● Plug & play comptible with Garmin GNS430,
         ● Flight management system interface,
         ● Weight: 3,0 kg

          More info                           Price: contact us

Discontinued
Contact us for availability
of used
GNS430(W) units.

Garmin GNS 430(W) - GPS/Nav/Com

           ● IFR certified GPS (TSO C146a)
           ● 4" (10 cm) display, resolution 240x128 pix
           ● 15 channel GPS WAAS satellite receiver
         ● Jepessen database with airspace,
                frequencies, radio beacons, airport info,
                approaches, holdings, SID & STAR,...
         ● Integrated VHF Com radio 25/8,33 kHz
           ● Integrated VOR/LOC/GS receiver
           ● Interfaces for CDI/HSI, fuel flow sensor,
                stormscope, autopilot, transponder, ...
           ● Weight: 3,0 kg

          More info                           Price: contact us

GPS/Com

Garmin GTN 635Xi - GPS/Com

         ● Menu-driven graphical interface,
         ● 4.9" (12.4 cm) LCD touchscreen display, 600x266 pix,
         ● Feature-rich MFD capabilities,
         ● GPS TSO'd to C146c, authorized for class 1,2,3 (LPV),
       ● GPS-WAAS-certified to Gamma-3 approach capability,
         ● VHF com transceiver with 25 or 8.33 kHz spacing,
         ● Com transmit power: 10W standard, 16W optional,
         ● Optional interface capabilities: lightning, weather,
              traffic, TAWS-B terrain alerting, and more,
         ● Integrated contol/display for remote transponders,
         ● Flight control system interface for select autopilots,
         ● Weight: 2,82 kg

          More info                        Price: contact us

GPS

Garmin GTN 725Xi - GPS

         ● Menu-driven graphical interface,
         ● 6.9" (17.5 cm) LCD touchscreen display, 600x708 pix,
         ● Feature-rich MFD capabilities,
         ● GPS TSO'd to C146c, authorized for class 1,2,3 (LPV),
       ● GPS-WAAS-certified to Gamma-3 approach capability,
         ● Optional interface capabilities: lightning, weather,
              traffic, TAWS-B terrain alerting, and more,
         ● Integrated contol/display for remote transponders
         ● Integrated control for remote audio panel functions,
         ● Flight control system interface for select autopilots,
         ● Weight: 3,52 kg

          More info                        Price: contact us

Garmin GTN 625Xi - GPS

         ● Menu-driven graphical interface,
         ● 4.9" (12.4 cm) LCD touchscreen display, 600x266 pix,
         ● Feature-rich MFD capabilities,
         ● GPS TSO'd to C146c, authorized for class 1,2,3 (LPV),
       ● GPS-WAAS-certified to Gamma-3 approach capability,
         ● Optional interface capabilities: lightning, weather,
              traffic, TAWS-B terrain alerting, and more,
         ● Integrated contol/display for remote transponders
         ● Flight control system interface for select autopilots,
         ● Weight: 2,48 kg

          More info                        Price: contact us

Wireless interfaces

   Garmin Flight Stream 510

          ● Multi Media Card with Bluetooth & Wifi interfaces
          ● Replaces SD datacard in GTN6xx/7xx navigators
          ● Communicates with tablet (iPad,...) or
               Garmin aera760/660
          ● Wireless flight plan transfer (Garmin Pilot app,
               ForeFlight,...)
          ● Wireless database updates (database concierge
               in Garmin Pilot app)

         More info                        Price: � contact us

   Garmin Flight Stream 210

          ● Bluetooth interface for GTN6xx/7xx & GNS430W
          ● Flight plan transfer from tablet to GTN/GNS
          ● Communicates with tablet (iPad,...) or Garmin
               aera760/660
          ● Wireless flight plan transfer (Garmin Pilot app,
               ForeFlight,...)
          ● Streaming of GPS location & AHRS backup attitude
               to tablet
          ● Weight: 0,12 kg

         More info                        Price: � contact us
